(Motor+ESC+Remote) E-mountainboard electric skateboard kit MTSVESC7.12 Supercase200A VESC75 based ESC and brushless black sealed motor (battle-hardened) and Remote

(Motor+ESC+Remote) E-mountainboard electric skateboard kit MTSVESC7.12 Supercase200A VESC75 based ESC and brushless black sealed motor (battle-hardened) and Remote

SKU:MTSVESC7.12 with case+MTO6355-170-HA-C+MTSKR20WFV2

Regular price $500.00
Regular price $625.00 Sale price $500.00
Sale Sold out
Shipping calculated at checkout.
ESC+Motor
Remote

Have Doubts? Contact US!!

(Motor+ESC+Remote)  E-mountainboard electric skateboard kit MTSVESC7.12 Supercase200A VESC6 VESC75 based ESC and brushless black sealed motor (battle-hardened) and Remote

Price includes 1pcs ESC and 1pcs motor and 1pcs Remote

1. Specifications of MTSVESC7.12 200A Supercase ESC based on VESC6 speed controller:
Model no
MTSVESC7.12 Supercase200A
Cont. Current
200A
Voltage
3-12S
Burst Current
300A
BEC
5V
PCB size
92*52*22 mm
Hardware
based on VESC75300
Firmware version
updatable
PCB net weight
160g
Aluminium Case
98.5*55.5*35mm
Feature
12pcs mosfets; 8-layer PCB; separate high current components and low-curent components to two PCBs
2. Motor specifications
First Generation Maytech sealed cover HALL SENSOR Motor
Model No. MTO6355-170-HA-C MTO6365-170-HA-C MTO6374-170-HA-C MTO8085-160-HA-C
KV 170  170  170  160
Idle Current 1.0A 0.8A 0.8A 1.5A
Max. Current 65A 65A 65A 90A
Input Volt 2-12s Lipo 2-12s Lipo 2-12s Lipo 6-14s Lipo
Max. Output Watt 3510W 3520W 3550W 5330W
Max. Pull 12000g 9700g 13000g 15500g
Rated Current 55A 60A 60A 64A
Motor Weight 605g 760g 830g 1115g
Shaft 8mm 8mm 8mm 12mm
Output shaft length 26mm 26mm 26mm 44mm
Resistance 0.0441  0.0402  0.0402  0.0280
Second Generation Maytech sealed cover HALL SENSOR Motor
Model No. MTO6355-170-HA-C2 MTO6365-170-HA-C2 MTO6374-170-HA-C2
KV 170  170  170
Idle Current 1.0A 0.8A 0.8A
Max. Current 65A 65A 65A
Input Volt 2-12s Lipo 2-12s Lipo 2-12s Lipo
Max. Output Watt 3510W 3520W 3550W
Max. Pull 12000g 9700g 13000g
Rated Current 55A 60A 60A
Motor Weight 610g 765g 860g
Shaft 10mm 10mm 10mm
Output shaft length 34mm 34mm 34mm
Resistance 0.0441  0.0402  0.0402
Third Generation Maytech sealed cover HALL SENSOR Motor with extra big bearing (more durable)
Model No. MTO6880-190-HA-C3 MTO6396-190-HA-C3
KV 190  190
Idle Current 0.8A 2A
Max. Current 65A 80A
Input Volt 2-12S Lipo 2-12S Lipo
Max. Output Watt 3550W 4550W
Max. Pull 13000g 13500g
Rated Current 60A 65A
Motor Weight 1200g 1280g
Shaft 10mm 10mm
Output shaft length 45.5mm 34mm
Resistance 0.0402  0.0200
3. Specification of MTSKR20WFV2 waterproof Remote controller with screen and receiver:
Model No. MTSKR2005WF (MTSKR20WFV2) Waterproof Rank IP66
Control Mode New Esk8 Application Only for Electric skateboard, elongboard, mountainboard
Speed Display Yes Travel Mileage Yes
Throttle and brake  Display ±100% VESC Control Mode Duty Cycle/ Current Mode
Speed Mode

3 speed modes, each mode can adjust speed from 1%-100% throttle

Accessories Wireless charging pad; receiver; 3pcs dupont cable
Charger

QC 2.0 wireless

Wireless Frequency 2.4GHz wireless with 40 channels
Display Screen

OLED yellow & blue screen

Triggers 2x high senstive triggers
Throttle and Brake Signal Output Range

1.5ms-2ms for throttle;

1.5ms-1ms for brake

Telemeter Data by Receiver Motor RPM; main battery voltage
Voltage Display

Remote & main battery voltage level (lithium iron; lithium ion battery optional)

Telemeter Data by VESC ESC voltage/ current/ temp; Motor temp/ RPM
Compatible ESCs

VESCTOOL/ Focbox/ Other PWM ESCs that has same signal output range with the remote

Receiver Built-in Switch for Esk8 Light / Esurf Water Pump

1x 30V 3A mechanical relay switch;

1x 20V 2A transistor electronic switch


MTSPF7.12K Port definations:

  1. USB port for programming;
  2. LED Port for connecting customer’s LED light to show ESC is on or off;
  3. Sensor port for motor Hall sensors (ABI, HALL, magnetic precision encoders);
  4. CAN Port for CAN communication with other devices and VESC arrays;
  5. COMM port for various kinds of other communication methods like I2C, ADC, Uart,You can use your Arduino or Raspberry Pi to control the VESC!
  6. PPM port to connect PPM transceivers.
